Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack

Ask Latest Price
Brand Name :Zon Pack
Model Number :ZH-1120S
Certification :CE
Place of Origin :China
MOQ :1SET
Price :USD800-2100/SET
Payment Terms :L/C D/A D/P T/T Western Union MoneyGram
Supply Ability :99sets/month
Delivery Time :25 working days
Packaging Details :wooden case
Machine name :Sealing machine
Sealing speed :10-30bags/min
Max weight :5 kg
Sealing type :Heat Sealing Plastic Bag
Seal Width(mm) :10
Model :ZH-1120S
more
Contact Now

Add to Cart

Find Similar Videos
Cookies Chips Pillow Bag Food Packing Machine Nitrogen Filling Multi Head 00:41
Cookies Chips Pillow Bag Food Packing Machine Nitrogen Filling Multi Head
Laundry Beads Counting Can Box Filling Machine High Speed 35 Bags/Min 00:33
Laundry Beads Counting Can Box Filling Machine High Speed 35 Bags/Min
Premade Bag Nut Food Packaging Machine Multihead Weighing Automatic 00:41
Premade Bag Nut Food Packaging Machine Multihead Weighing Automatic
Premade Bag Pouch Packing Machine Laundry Beads Counting 20pcs 30pcs 02:00
Premade Bag Pouch Packing Machine Laundry Beads Counting 20pcs 30pcs
50Bags/Min 14 Heads Automatic Food Packaging Machine For Biscuit Candy 00:45
50Bags/Min 14 Heads Automatic Food Packaging Machine For Biscuit Candy
PLC Automatic Rotary Packing Machine With Multihead Weigher 00:45
PLC Automatic Rotary Packing Machine With Multihead Weigher
Zip Lock Premade Bag Packaging Machine For Beef Jerky Dried Meat 00:42
Zip Lock Premade Bag Packaging Machine For Beef Jerky Dried Meat
10 Heads 14 Heads Multihead Weighe For Vegetable Packing 00:33
10 Heads 14 Heads Multihead Weighe For Vegetable Packing
Multi Function Tomato Fruits Weighing And Packing Machine With Multihead 00:30
Multi Function Tomato Fruits Weighing And Packing Machine With Multihead
View Product Description

Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack

1. Product Application

The machine can seal all kinds of heat sealable materials, which adopts constant temperature control system and stepless speed adjusting transmission mechanism. Both temperature and height of conveyor table are adjustable. The machine works with solid-ink coder or color ribbon printer to print the colored labels while sealing. They are able to print at high speed with instant dry and highly legible letters that have a good adhesion property. Various colors are selectable. Counting device is optional.

2. Parameter Of Sealing Machine
Model ZH-1120S
Voltage (V/Hz) AC 380/50 220/50
Motor Power (W) 245
Sealing Power (W) 300×2
Printing Heating Power(W) 40×2
Speed(m/min) 0-12
Seal Width(mm) 10
Temperature Range(℃) 0-300
Printing Type Solid ink roller
Distance from Sealing Center to Conveyor (mm) 100-500
Height from seal Head to Floor(mm) 700-1100
Conveyor Size(L×W )(mm) 1400×250
Max. Conveyor Load for Single Bag(kg) 5
Overall Conveyor Load(kg) 15
External Dimensions(L×W×H) (mm) 1450×680×1480
Net Weight (kg) 100

3. Bag sealing type

Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food SnackPlastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack

4. Main Features

1) Simple structure type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Height can be adjusted according to the bag length

6)Can printe the date in the bag when it sealing

5. Machine Options

Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack

6. Machine details

Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack

7. Company profile

Plastic Bag Heat Sealing Machine Continuous Seal Premade Bag For Food Snack
